NII, NTT, and NTT EAST Achieve World's First Successful Demonstration of Rapid Optical Wavelength-Path Switching and Addition Through Automated Optical Transport Layer Control Based on Network Conditions

~Enabling traffic rerouting within 10 minutes during severe disasters~

News Highlights

TOKYO - December 18, 2025 - National Institute of Informatics, Research Organization of Information and Systems, Inter-University Research Institute Corporation (Head Office: Chiyoda-ku, Tokyo; Director-General: Sadao Kurohashi; hereinafter "NII"), NTT, Inc. (Headquarters: Chiyoda-ku, Tokyo; President and CEO: Akira Shimada; hereinafter "NTT"), and NTT EAST, Inc. (Headquarters: Shinjuku-ku, Tokyo; President and CEO: Naoki Shibutani; hereinafter "NTT EAST") have successfully demonstrated the world's first automated optical transport layer control enabling wavelength-path switching with a wavelength conversion and on-demand wavelength-path provisioning within the APN architecture. These capabilities help maintain network connectivity during severe disasters. The ability to rapidly switch and add optical wavelength-paths is expected to contribute to the realization of a highly reliable and flexible communication infrastructure that supports advanced research.

Background

The academic information network (SINET)⁵, built and operated by NII, serves as Japan's nationwide academic information infrastructure for universities and research institutions. Through regional SINET connection points, institutions across the country are interconnected, forming a national communication network that supports Japan's academic research with ultra-high-speed links of 400 Gbps. In recent years, the volume of research data, including data generated by large-scale experimental facilities and big-data applications, has been increasing rapidly. As a result, strengthening communication reliability to enable uninterrupted transfer of these growing datasets has become increasingly important.

Large-scale disasters such as earthquakes, storms, and floods have repeatedly caused communication failures, including fiber cuts. When optical fibers are damaged during a severe disaster, network services are typically protected by immediately switching to a pre-configured backup path (protection switching)⁶. Here, it is necessary to prepare for the risk of prolonged outage even after the switchover, and to consider switching to a new backup route. However, after protection switching, securing a new backup path (restoration switching)⁷ requires advance preparation of wavelength resources and equipment. In addition, the assessment and selection of transport paths are often performed manually, which means that identifying and securing an alternative path and rerouting traffic can take several hours.

NTT has been developing technologies that enable rapid restoration switching by automatically identifying and switching to alternative paths during severe disasters, as well as on-demand optical wavelength-path provisioning. These efforts include the development of an APN controller that automatically evaluates and configures optimal optical signal rates, modulation formats⁸, and wavelengths.

In this project, NTT EAST's existing commercial optical fiber cables were combined with NTT's transport equipment, APN controller, wavelength converter, and switches with optical transceivers to construct an optical transport network. By integrating NII's IP controller and data transfer server (MMCFTP)⁹, coordinated multi-operator control between the two controllers was achieved. This environment enabled demonstration experiments for two use cases: wavelength-path switching and on-demand wavelength-path addition (bandwidth upgrade).

Figure 1 Overview of optical wavelength path rerouting (restoration switching) through coordinated control using the APN controller and IP controller

Research Results

Two use-case verification tests were conducted in an optical transport network environment connecting three data centers (A, B, and C) in Tokyo via optical fiber.

Experiment 1: Optical wavelength path rerouting (Figure 2)

This experiment assumed a scenario where a severe disaster disrupts the transport path carrying advanced research traffic. The following sequence was tested to verify the system's ability to automatically perform restoration-based rerouting to recover traffic transfer.

As the result of the experiment, we confirmed that all traffic transfer was restored within 10 minutes from the start of the rerouting operation.

Figure 2 Configuration of Experiment 1

Experiment 2: On-demand capacity expansion (Figure 3)

This experiment assumed a scenario where bandwidth needs to be expanded depending on the progress of advanced research activities. By applying the automated switching technique verified in Experiment 1, the automated on-demand configuration for capacity expansion was verified.

As the result of the experiment, we confirmed that all traffic was successfully transferred through the expanded optical wavelength-path.

Figure 3 Configuration of Experiment 2

Key Technical Features

(1) APN controller enabling on-demand configuration of optical wavelength-paths

Under current operations, establishing or upgrading optical wavelength-paths requires multiple manual processes, including checking equipment and wavelength resources, selecting transport paths, and assessing transmission reachability based on optical fiber conditions. If end-to-end wavelength resources or transmission reachability cannot be secured, the transport path or transmission method (such as modulation format) must be reconsidered, which can delay provisioning by several hours or more.
The APN controller technology developed in this project automates and centrally manages the design of optimal paths, wavelengths, and transmission methods, including those involving wavelength converters, even when end-to-end wavelength resources cannot be secured. This enables rapid provisioning and control operations such as transport path switching.

(2) Wavelength conversion technology

Configuring an optical wavelength-path typically requires securing the same wavelength end to end. However, in scenarios such as major disasters requiring multiple on-demand bypass paths, or when wavelength resources are constraint, this may not be possible. Traditionally, this issue has been addressed by installing expensive transponders along the path to convert the optical signal into an electrical digital signal before wavelength conversion, which increases latency and power consumption due to digital signal processing.
The newly developed technology enables wavelength conversion with minimal additional latency and power consumption, allowing flexible and efficient configuration of optical wavelength-paths.

(3) Control-domain separation technology for flexible service delivery models

As optical transceivers¹⁰ continue to be miniaturized, routers and switches capable of directly housing these transceivers have begun to emerge. This allows them to connect directly to the APN, reducing equipment footprint and lowering equipment costs. However, APN connectivity requires configuration tasks such as setting wavelengths and laser power for the optical transceivers and performing optical-layer monitoring, which raises concerns about operational complexity.
With this technology, layer 2 and layer 3 functions traditionally handled by routers and switches, such as routing and VLAN configuration, are separated from optical-layer control required for APN connectivity. By allowing the APN service provider to manage optical transceivers through the APN controller, service network operators and users can utilize high-speed, low-latency transmission services without needing to be aware of optical-layer operations.

Figure 4 Implementation overview of the key technologies

Roles of Each Organization

Figure 5 Roles of each organization

Future Outlook

This demonstration confirmed that multi-layer coordination enables automatic discovery and provisioning of backup paths during a major disaster, allowing traffic rerouting within 10 minutes. These results are expected to further improve the reliability of optical transport networks.

NII supports the advancement of academic research and education throughout Japan by developing SINET, one of the world's highest-performance network platforms. NII will continue to pursue higher speed and capacity, as well as improved reliability and stability.

NTT will continue to promote the wider deployment of IOWN APN and advance the development of technologies that enhance the reliability of optical transport networks and enable on-demand network provisioning, along with studying new use cases.

NTT EAST will continue to pursue further advancements toward the realization of services that fully leverage a high-capacity and highly reliable optical transport network.

Related Past Press Releases

<Glossary>

¹The world's first
As of December 18, 2025, according to NTT

²Optical wavelength-path
An optical wavelength-path refers to the path taken by an optical signal as it is transmitted from a transmitter to a receiver within an optical transport network.

³APN (All-Photonics Network)
APN introduces photonics-based technologies throughout the entire system from the network to end devices. This approach enables ultra-low power consumption, high quality and high capacity transmission, and low latency performance that are difficult to achieve with conventional electronics-based technologies. For more details, please refer to the following page:
What is APN?
https://group.ntt/en/group/iown/function/apn.html

⁴APN controller
APN controller (APN-C) provides essential functions to operate APN, including end-to-end optical wavelength-path configuration through control of optical transport equipment and optical transceivers (and transponders), service activation and maintenance, and various operational information collection. It is one of the key components for realizing APN.

⁵SINET
SINET is an academic network that supports joint use of large-scale research facilities, strengthens collaboration across research fields, promotes international research cooperation, enables academic information sharing and big data exchange, enhances the quality of university education, and supports regional revitalization through knowledge-driven initiatives and industry–academia collaboration. Nodes are deployed in all prefectures, interconnected by 400 Gbps links (and two 100 Gbps links for Okinawa), providing services to more than 1,000 universities and research institutions.

⁶Protection switching
Protection switching is a redundancy technology that minimizes service downtime during failures in optical transport networks by immediately switching traffic to a pre-established backup path. To ensure rapid switchover, unused backup paths are prepared in advance and optical signals are kept continuously active on the backup links.

⁷Restoration switching
Restoration switching is a technology that restores traffic during optical transport network failures by dynamically searching for a new bypass path and remotely adjusting the wavelength and path of existing optical transceivers. It is based on CDC-ROADM (Colorless, Directionless, Contentionless Reconfigurable Optical Add/Drop Multiplexer), which maximizes flexibility in optical signal routing.

⁸Modulation format (Transmission format)
A modulation format refers to the combination of baud rate (the number of modulation events per second) and modulation scheme (such as QPSK or 16QAM). Even at the same signal rate, different combinations of baud rate and modulation scheme result in significantly different transmission distances. Therefore, selecting an appropriate modulation format is important to satisfy requirements for signal rate and transmission distance.

⁹MMCFTP
MMCFTP is a file transfer protocol that achieves stable, ultra-high-speed data transfer by dynamically adjusting the number of TCP connections based on network conditions such as latency and packet loss. It is characterized by the use of a large number of simultaneous TCP connections when transferring big data.

¹⁰Optical transceiver
A device that transmits and receives optical signals.
